上海閥(fa)(fa)盛閥(fa)(fa)門制造有(you)限公司主要(yao)生產低(di)(di)功(gong)(gong)(gong)率(lv)(lv)氣(qi)液電(dian)(dian)(dian)(dian)磁(ci)(ci)(ci)閥(fa)(fa)，可(ke)提供(gong)低(di)(di)功(gong)(gong)(gong)率(lv)(lv)氣(qi)液電(dian)(dian)(dian)(dian)磁(ci)(ci)(ci)閥(fa)(fa)價格，低(di)(di)功(gong)(gong)(gong)率(lv)(lv)氣(qi)液電(dian)(dian)(dian)(dian)磁(ci)(ci)(ci)閥(fa)(fa)說(shuo)明書，低(di)(di)功(gong)(gong)(gong)率(lv)(lv)氣(qi)液電(dian)(dian)(dian)(dian)磁(ci)(ci)(ci)閥(fa)(fa)實物(wu)圖(tu)，低(di)(di)功(gong)(gong)(gong)率(lv)(lv)氣(qi)液電(dian)(dian)(dian)(dian)磁(ci)(ci)(ci)閥(fa)(fa)結構圖(tu)，低(di)(di)功(gong)(gong)(gong)率(lv)(lv)氣(qi)液電(dian)(dian)(dian)(dian)磁(ci)(ci)(ci)閥(fa)(fa)外形(xing)尺寸，低(di)(di)功(gong)(gong)(gong)率(lv)(lv)氣(qi)液電(dian)(dian)(dian)(dian)磁(ci)(ci)(ci)閥(fa)(fa)執(zhi)行標(biao)準，低(di)(di)功(gong)(gong)(gong)率(lv)(lv)氣(qi)液電(dian)(dian)(dian)(dian)磁(ci)(ci)(ci)閥(fa)(fa)工作原理，低(di)(di)功(gong)(gong)(gong)率(lv)(lv)氣(qi)液電(dian)(dian)(dian)(dian)磁(ci)(ci)(ci)閥(fa)(fa)作用特點。

低功率氣液電磁閥技術說明：

適用介質：水、氣、油

介質溫度：-10～80℃

動作方式：先導式

工作壓差：見下表（常閉）

閥體材料：黃銅（HPb59-1）

膜片密封，材料：丁腈橡膠

線圈保護等級：塑封線圈IP65

電壓波動范圍：AC -15%～10% DC -5%～10%

低功率氣液電磁閥主要技術參數 （注：介質溫度最高120℃時請選用氟橡膠膜片密封）： 產品型號 流量孔徑（mm） 螺紋G 工作壓差（bar） Cv值 A B （mm） （mm） RSQ-15 13.5 G3/8″ G1/2″ 0.5～16 4.5 66 82 RSQ-20 18 G3/4″ 0.5～12 5.8 79 89 RSQ-25 24 G1″ 0.5～12 14 105 106
