液用電磁閥

產品名稱：國產激情久久久久影院小草:液用電磁閥
產品型號：DF/ZCS
產品口徑：DN15-50mm
產品壓力：1.6Mpa
產品材質：黃銅、不銹鋼
聯系電話：021-51061127
聯系傳真：021-51062214
Email：fashengfamen@126.com
聯系人：陳云非
聯系手機：18217570461
QQ：203398752
公司名：上海閥盛閥門制造有限公司
帳號：03416900040048386
開戶行：農行上海水清南路支行
售后承諾：質保一年，質量三包：包修、包換、包退。

上海閥(fa)(fa)(fa)盛閥(fa)(fa)(fa)門(men)制造有限公司主要生產液(ye)(ye)用(yong)(yong)(yong)(yong)(yong)電(dian)(dian)(dian)(dian)磁(ci)(ci)閥(fa)(fa)(fa)，可提供液(ye)(ye)用(yong)(yong)(yong)(yong)(yong)電(dian)(dian)(dian)(dian)磁(ci)(ci)閥(fa)(fa)(fa)價格，液(ye)(ye)用(yong)(yong)(yong)(yong)(yong)電(dian)(dian)(dian)(dian)磁(ci)(ci)閥(fa)(fa)(fa)說明書，液(ye)(ye)用(yong)(yong)(yong)(yong)(yong)電(dian)(dian)(dian)(dian)磁(ci)(ci)閥(fa)(fa)(fa)實物圖，液(ye)(ye)用(yong)(yong)(yong)(yong)(yong)電(dian)(dian)(dian)(dian)磁(ci)(ci)閥(fa)(fa)(fa)結構圖，液(ye)(ye)用(yong)(yong)(yong)(yong)(yong)電(dian)(dian)(dian)(dian)磁(ci)(ci)閥(fa)(fa)(fa)外形(xing)尺寸(cun)，液(ye)(ye)用(yong)(yong)(yong)(yong)(yong)電(dian)(dian)(dian)(dian)磁(ci)(ci)閥(fa)(fa)(fa)執行(xing)標準，液(ye)(ye)用(yong)(yong)(yong)(yong)(yong)電(dian)(dian)(dian)(dian)磁(ci)(ci)閥(fa)(fa)(fa)工作(zuo)原理，液(ye)(ye)用(yong)(yong)(yong)(yong)(yong)電(dian)(dian)(dian)(dian)磁(ci)(ci)閥(fa)(fa)(fa)作(zuo)用(yong)(yong)(yong)(yong)(yong)特點。

液用電磁閥詳細介紹：
適用介質：液體、氣體，油（20CST以下）
工作型式：先導式
密封件材質：丁腈橡膠（NBR）
線圈保護系數：鐵殼線圈IP54

液用電磁閥技術參數（N/C）：

型號	連接尺寸	通徑	CV值	長（L）	高（H）	介質溫度	工作壓力（壓差）	額定電壓	材質
DF-15	G1/2"	15	3.73	80	105	-5 ~ 80℃	0.3~8kgf/cm² 最大耐壓力16kgf/cm²	220V AC/50HZ 110V AC/50HZ DC24V 其他電壓可已定制	鍛黃銅
DF-20	G3/4"	20	7	87	112
DF-25	G1"	25	11.1	108	124
DF-32	G1¼"	32	14	130	141
DF-40	G1½"	40	24.5	145	149
DF-50	G2"	50	35	177	164
DF-40F	法蘭4-Φ18孔距Φ110	40	24.5	165	196				銅體鋼法蘭
DF-50F	法蘭4-Φ18孔距Φ125	50	35	210	200				銅體鋼法蘭
